TMAX™ 2
Heavy-duty work requires a reliable, heavy-duty mechanic truck, and that describes the TMAX 2 to a T. Like all Stellar equipment, the TMAX 2 begins with professional engineering and top-quality materials. Add in precision construction, and it’s no wonder the TMAX 2 Mechanic Truck has a reputation as a durable workhorse.
Customer Story: See why “Gold Rush: Dave Turin’s Lost Mine” chooses Stellar.
10+ available in Inventory
PrintAdditional Information
The TMAX 2 is available in aluminum in multiple configurations, including a design for a low cab-forward (LCF) chassis.
For added capabilities and convenience, the crane pedestal/compartment is constructed of steel material capable of handling the robust lifting capacity of Stellar cranes equipped with CDTpro™ control systems while providing the same storage space as other, non-reinforced compartments.
- Available in either 11′ or 14′ bodies.
- Stellar’s torq-isolator crane support design isolates the crane compartment from the rest of the side pack.
- Lifting stresses are transferred to the stabilizers and box-type subframe, not the compartment doors.
- Aluminum extruded top with drill-free mounting rails make it easy to add a wide range of mechanic service truck accessories.
- Mounting rails integrated within compartments allow for fully customizable configurations.
- Aluminum sidepack and doors reduce weight and corrosion, allowing for more payload and longer life.
- Ease of wiring access with added pre-drilled holes between compartments for seamless wiring installation.
- Bodies feature a 21″ or 30″ steel workbench bumper with an integrated full-width long bar storage compartment and vise mounts.
- Roller-type boom support helps center the crane boom when stowing.
- Stainless-steel billet-style hinges have hidden fasteners and a rugged 5/16″ stainless-steel rod for years of heavy use.
- Rotating master-lock system for security.
- Exterior mounted light box provides easy mounting for work lights and other accessories while minimizing entry points into the body.
- 3-point compression latches keep weather-stripping tight while allowing easy access.
- Easily add a wide range of mechanic service truck accessories, like bale handle drawer sets and bolt bins for better organization.
- Double-panel 1/8″ aluminum tailgate with hinged arm brackets provides a stout working surface.
- 250-lb capacity, adjustable divider shelves made of spangled galvanized steel.
- Hydraulic reservoir design features a top-mounted filter for easier maintenance.
- Complete undercoating, with minimum of 6.5 mils of petroleum base material, provides extra protection from corrosion and road debris.
- Mudflaps positioned to wire guards to avoid interference with exhaust systems.
Models:
- TMAX 2-11
- TMAX 2-14
- TMAX 2-14 Low Cab-Forward
Store Your Long Chains & Tools
With the pull-out drawer on our innovative Workbench Bumper Drawer System, you get lockable storage space for chains, long tools and more. Contact our sales team for details.
Works With CDTpro™ Control System
Several cranes compatible with the TMAX 2 feature the new CDTpro Control System. Its innovative, industry-only Range Finder™ technology provides real-time max lifting capacity from any point as you walk around the crane.
Specifications
| TMAX 2-11 | TMAX 2-14 | TMAX 2-14 Low Cab-Forward | |
|---|---|---|---|
| Applicable Chassis: | 25,500 – 33,000 GVWR (22.5 tire size) | 25,500 – 33,000 GVWR (22.5 tire size) | 25,500 – 33,000 GVWR (22.5 tire size) |
| Body Height: | 60" (152 cm) | 60" (152 cm) | 60" (152 cm) |
| Body Width: | 94" (239 cm) | 94" (239 cm) | 94" (239 cm) |
| Floor Width: | 50" (127 cm) | 50" (127 cm) | 50" (127 cm) |
| Compartment Depth: | 22" (56 cm) | 22" (56 cm) | 22" (56 cm) |
| Clear Cab to Axle: | 84" (213 cm) | 120" (305 cm) | 120" (305 cm) |
| Body Length: | 133" (338 cm) | 169" (429 cm) | 169" (429 cm) |
| Net Weight: | Aluminum: 3,459 – 3,544 lbs (1,569 – 1,607 kg) Steel: 4,388 – 4,469 lbs (1,991 – 2,027 kg) |
Aluminum: 3,960 lbs (1,797 kg) Steel: 5,140 lbs (2,332 kg) |
Aluminum: 3,665 lbs (1,662 kg) |
Compatible Cranes
| Crane Rating | Max. Reach | Max. Capacity | Control Systems | |
|---|---|---|---|---|
| Hydraulic Cranes | ||||
| 7621 | 44,840 ft-lb* | 21' (6.40 m) | 7,500 lbs (3,402 kg) | CDTpro™ |
| 7630 | 44,840 ft-lb* | 29' 8" (9.04 m) | 7,500 lbs (3,402 kg) | CDTpro™ |
| 8621 | 53,100 ft-lb* | 21' (6.40 m) | 8,600 lbs (3,900 kg) | CDTpro™ |
| 8630 | 53,100 ft-lb* | 29' 8" (9.04 m) | 8,600 lbs (3,900 kg) | CDTpro™ |
| 10621 | 70,800 ft-lb* | 21' (6.40 m) | 10,000 lbs (4,082 kg) | CDTpro™ |
| 10630 | 70,800 ft-lb* | 29' 9" (9.07 m) | 10,000 lbs (4,082 kg) | CDTpro™ |
| 12621 | 77,800 ft-lb* | 21' (6.40 m) | 12,000 lbs (5,443 kg) | CDTpro™ |
| 12630 | 77,800 ft-lb* | 29' 9" (9.07 m) | 12,000 lbs (5,443 kg) | CDTpro™ |
Videos
Awards
Optimize your Service vehicle
Because different people use service vehicles in different ways, Stellar makes it easy to outfit yours with a wide range of accessories.
